300W LED dual color imaging lightI(P65)

300W LED dual color imaging lightI(P65)

LED light source: TX-4566RGBLA300

LED quantity: 1

LED color: pure white warm white

Lens angle: 19 degrees

Channel mode: 6/10 channel mode

Display: LCD liquid crystal display

Control method: standard DMX-512, RDM

RDM: two-way communication

Cooling system: temperature control, overheating protection

Dimming: 0-100% linear dimming

Strobe frequency: 20 Hz

Built-in effects: LED built-in rich macro function effects

Color: 5 colors can be changed at will

Signal connection: IP65 DMX signal 5-pin or 3-pin input/output

Power connection: IP65 power supply XLR input/output

Rated voltage: 100-240V AC / 50-60Hz

Rated power: 300W

Maximum ambient temperature: -30°C / 86°F, 50°C / 122°F

Operating position: all directions

Standing: Light stand installation

Suspension: quick lock

Safety rope: hanging point

Simple package: carton packaging (inner and outer 2-layer packaging)

Long distance transportation: 1 pack of 4 flight boxes

 Chassis color: black

Length: 710 mm Width: 310 mm Height (horizontal direction of lamp head): 280 mm

Single carton size: length: 750mm width: 320 mm height: 290 mm

Net weight: 11.6 kg
